Siemens XC1001-A Extinguishing panel Standard

Siemens · siemens fire control

Siemens XC1001-A Extinguishing panel Standard

Manufacturer: SiemensModel: Siemens XC1001-A Extinguishing panel Standard

We are providing a Premium Quality range of  Siemens XC1001-A Extinguishing panel Standard in India.

Request price & availability

Prices are quoted on request — no online checkout.

Not sure this is the right variant? Ask us to check it.

Specifications & details

The compact dimensions of the Standard variant of XC1001-A are ideally adapted for single-sector applications, small to medium installations. It provides a full range of monitored inputs and outputs as well as digital and relay outputs. Self-contained control panel including fire detection and extinguishing control. The configurable relay outputs can be used to transmit information to a FS20/FS720 fire detection panel via FDnet/C-NET I/O modules. The detection lines can be configured to AlgoRex‚ Cerberus PRO‚ Sinteso and Synova conventional and collective devices. Easy and fast commissioning using 4 digital displays.

Mains voltage AC 115…230 V / +10…-15 %, 50/60 Hz
Power consumption 150 VA
Alarm relay output (NO/NC) 30 V / 1 A max.
Battery capacity 2 x 12 V / 4.5 Ah
Operating temperature -5…40 °C
Conventional line 3
Control output 24 V / 1 A max.
Control input 4 monitored inputs (loss of agent, pressure switch) 4 non monitored inputs (activation via contacts)
Storage temperature -20…+60 °C
Standard EN 12094-1 , EN 54-2/A1 , EN 54-4/A2
Case protection category IP30
Color housing/cover / Signal white, ~RAL 9003
Color Grey white, RAL 9002
Dimensions (W x H x D) 370 x 286 x 90 mm
Dimensions (W x H x D) 370 x 286 x 90 mm
Weight (net) 4.1 kg
Operating altitude, max. 4000 m

Next step

Quote for Siemens XC1001-A Extinguishing panel Standard

Send quantity and delivery city; we confirm the exact variant and lead time.
