Overview

EKA  is a leading dealer and distributor of Siemens Motion Controllers in India. We distribute Siemens Motion Controllers in Chennai, Bangalore, Pune, Mumbai, Ahmedabad, Hyderabad and Delhi.

Let’s start with the basics. Motion controllers are special devices that control the engine operating modes. In other words, it’s the brain of every motion control system. As such, its task is telling the motor what to do based on the desired production outcome.

Movement Profiles and Target Positions

In fact, a motion controller contains the movement profiles and the target positions for the application, and creates the trajectories that the engine must perform to satisfy the commands. Motion control is often a closed circuit, so controllers monitor the actual path and corrects positioning or speed errors.

SIMOTION Motion Control System

SIMOTION is a high-performance motion control system designed for various machine concepts, offering maximum modularity and flexibility. With SCOUT TIA, it provides consistent engineering fully integrated into the TIA Portal. It also supports drive-integrated SINAMICS safety functions for customized safety solutions. The latest software versions enable object-oriented programming (OOP), OPC UA communication, and hardware-free program testing, further enhancing SIMOTION’s modularity, openness, and efficient software development.

SIEMENS MOTION CONTROLLERS

SIEMENS MOTION CONTROLLER – SIMOTION D – Drive-based

Our drive-based motion controller SIMOTION D integrates motion control, technology, and PLC functions directly into the drive. Your benefits: high machine cycle rates, reproducible product quality, significant cost savings, and reduced space requirements inside the control cabinet.

Highlights

Compact, flexibly scalable, economical, and highly responsive: With SIMOTION D, the PLC, technology, and motion control functions are integrated directly into the control module of the SINAMICS S120 drive system.
SIMOTION D requires about 50 percent less space than a conventional PLC with separate drive control. This makes the system ideal for distributed or modular automation solutions, particularly with complex machines requiring highly time-critical axis synchronization.
Integrated cost-efficiency
Significant cost savings throughout the entire life cycle thanks to the integration of motion control, technology, and PLC functions directly into the drive
Compact design
The space-saving design permits a much smaller control cabinet volume.
Response speed
With a minimum of 0.125 ms clock cycles, SIMOTION D responds extremely quickly to requirements because there are no interfaces
Precisely scalable performance
SIMOTION D adapts to your requirements: as a SIMOTION D410-2 single-axis system with a multi-axis option or as a SIMOTION D4x5-2 multi-axis system in four performance versions.

Applications

High-end machines
The ideal solution for complex multi-axis machines  requiring shortest cycle times as well as optimal product quality through a deterministic and reproducible machine behavior.
Compact machines
SIMOTION D is recommended wherever there is a need to implement complex applications in a small space. As the controller and drive are combined in a single system, SIMOTION D takes up very little space in the control cabinet.
Modular machines
In modular environments SIMOTION D is available, for example, as a supplement to the SIMOTION P or SIMOTION C system. The systems are connected via PROFINET with IRT.
Distributed automation solutions
SIMOTION D scores with multi-axis machines whose modules are each controlled by a SIMOTION controller, which mutually exchange process values in isochronous mode (distributed gearing).
Harsh conditions
With the SIPLUS variants, SIMOTION D is optimized for use under tough operating conditions (e.g. in atmospheres with harmful gases).

SIEMENS MOTION CONTROLLER – SIMOTION P – PC-based

Our SIMOTION P PC-based motion control system combines the robustness and openness of an industrial PC with full motion control capabilities. SIMOTION P is ideally suited for tough conditions, since the IPC design uses no rotating components such as fans or hard drives.

Highlights

High performance yet flexible: the SIMOTION P industrial PC impresses with its powerful PLC and full motion control functions.
With its broad range of PLC and motion control functionalities, SIMOTION P is suited for a wide range of applications, and its open Windows operating system makes it easy to integrate.
SIMOTION P scores with excellent flexibility – when selecting operating systems and processors, assembly options, or the wide range of communication interfaces.
Thanks to the latest PC processing architecture and cycle times of 0.250 ms with PROFINET IRT, SIMOTION P is also a strong performer.
Cost-efficiency
The powerful performance and compact, maintenance-free design ensure significant cost savings
Flexibility
Powerful motion control and PLC functionality for standard and embedded applications. Variable assembly options and the open Windows operating system offer additional flexibility.
User-friendliness
There are no maintenance expenses with SIMOTION P since it uses no fans, batteries or rotating components (such as a hard drive). The system is easy to configure: PLC and motion control applications, for example, run using the same program, and HMI Runtime can be run in parallel on the PC.
Openness
The Windows operating system of SIMOTION P makes it possible to perform complex data evaluations, display functions, or engineering tasks directly from your PC.
Customized communication
SIMOTION P comes with PROFINET onboard with three ports, and an Industrial Ethernet interface. The system can optionally be expanded using a plug-in IsoProfibus board.

Applications

High-performance applications
With its high processor performance and motion control software, SIMOTION P320-4 is predestined for applications with maximum performance requirements (such as hydraulic applications with highly dynamic position and pressure control loops).
Retrofitting solutions
Its ease of assembly makes SIMOTION P suitable not only for new systems but also for existing facilities that require retrofitting to bring them up to a future-proof state of the art.
Robust applications
By avoiding the use of rotating parts in the PC, the SIMOTION P320-4 is extremely well-suited for robust applications.
Applications using the Windows operating system
Based on the Windows operating system, SIMOTION P makes the best possible use of the openness of standard applications, like flexible networking, data storage capacity, and integrated communication.

SIEMENS MOTION CONTROLLER – SIMOTION C – PLC-based

Peripheral modules from the SIMATIC S7-300 line can be added to SIMOTION C complementary to the integrated onboard I/Os. The modular design in SIMATIC S7-300 design makes the PLC-based motion control system particularly flexible. With its outstanding variety of possible interfaces, SIMOTION C can be integrated in a wide range of environments.

Highlights

Flexible, versatile, powerful: With its outstanding variety of interfaces, SIMOTION C is one of the most communicative motion controllers for servo, stepper, and hydraulic drives.
SIMOTION C can be used extremely flexibly. In addition to the interfaces already integrated, peripherals from the SIMATIC S7-300 modules range can be added to the motion controller, and it scores wherever maximum flexibility in selecting the drives is required.
The PLC-based system can handle a wide range of processor signals and also manages high-end motion control functionalities, such as path interpolation and distributed gearing.
Cost efficiency
Significant cost savings thanks to top performance and easy adaptation to your applications.
Flexibility
Powerful motion control and PLC functionality in SIMATIC S7-300 design with a wide range of available interfaces.
User-friendliness
User-friendly handling and simple, fanless design.
Customized communication
SIMOTION C comes with standard interfaces for servo, stepper, and hydraulic drives or with PROFINET (three ports) onboard.

Applicatons

Modular applications
SIMOTION can be expanded as needed, with eight slots for peripheral modules according to the SIMATIC S7-300 design. Eight additional peripheral modules can be connected via IM 365.
Retrofit solutions
SIMOTION C can be easily equipped with the interfaces needed for your environment, giving your retrofit solution a substantial boost in performance without effort.
Plants with different drive solutions
SIMOTION C can be easily adapted to your infrastructure thanks to the wide range of possible expansions. From servo and stepper drives to hydraulic drives, the versatility of the modular motion controller provides optimum support for your application.
Interface diversity
From interfaces for analog, digital, stepper, and hydraulic drives to PROFINET, PROFIBUS, and Industrial Ethernet, the available SIMOTION C variants feature a wide range of connectivity options.
